Unity 应用接入¶

Assets/Plugins
├── Android
│   ├── FTUnityBridge.java                  // Android bridge
│   ├── InnerClassProxy.java                // Android Inner Setting Proxy
│   ├── ft-sdk-release.aar                  // Android SDK
│   ├── gson-2.8.5.jar                      // Android SDK 依赖第三方库
├── iOS
│   ├── FTMobileSDK.xcframework             // iOS SDK
│   ├── FTUnityBridge.mm                    // iOS bridge
├── FTSDK.cs                                // FTSDK.prefab 绑定脚本
├── FTSDK.prefab                            // SDK 初始化预制件
├── FTUnityBridge.cs                        // Unity bridge 桥接 iOS Android 等平台方法
├── FTViewObserver.cs                       // FTViewObserver.prefab 绑定脚本
├── FTViewObserver.prefab                   // View 页面监听预制件
├── UnityMainThreadDispatcher.cs            // UnityMainThreadDispatcher.prefab 绑定脚本
├── UnityMainThreadDispatcher.prefab        // 主线程消费队列预制件

FTUnityBridge.Install(new SDKConfig
            {
                datakitUrl = "http://10.0.0.1:9529",
                env = "prod",
                debug = true,

            });

FTUnityBridge.InitRUMConfig(new RUMConfig()
            {
                androidAppId = "androidAppId",
                iOSAppId = "iOSAppId",
                sampleRate = 0.8f,
            });

FTUnityBridge.InitLogConfig(new LogConfig
            {
                sampleRate = 0.9f,
                enableCustomLog = true,
                enableLinkRumData = true,
            });

FTUnityBridge.InitTraceConfig(new TraceConfig
            {
                sampleRate = 0.9f,
                traceType = TraceType.DDTrace,
                enableNativeAutoTrace = true,
                enableLinkRumData = true

            });

/// <summary>
///  添加 Action
/// </summary>
/// <param name="actionName"> action 名称</param>
/// <param name="actionType"> action 类型</param>
public static void StartAction(string actionName, string actionType)

/// <summary>
/// 添加 Action
/// </summary>
/// <param name="actionName">action 名称</param>
/// <param name="actionType">action 类型</param>
/// <param name="property">附加属性参数</param>
public static void StartAction(string actionName, string actionType, Dictionary<string, object> property)

 FTUnityBridge.StartAction("click", "test");

/// <summary>
///  View 开始
/// </summary>
/// <param name="viewName">当前页面名称</param>
public static void StartView(string viewName)

/// <summary>
/// View 开始
/// </summary>
/// <param name="viewName">当前页面名称</param>
/// <param name="property">附加属性参数</param>
public static void StartView(string viewName, Dictionary<string, object> property)

/// <summary>
/// View 结束
/// </summary>
public static void StopView()

/// <summary>
/// View 结束
/// </summary>
/// <param name="property">附加属性参数</param>
public static void StopView(Dictionary<string, object> property)

FTUnityBridge.StartView("TEST_VIEW_ONE");

FTUnityBridge.StopView();

/// <summary>
///  resource 开始
/// </summary>
/// <param name="resourceId">资源 Id</param>
/// <returns></returns>
public static async Task StartResource(string resourceId)

/// <summary>
/// resource 开始
/// </summary>
/// <param name="resourceId">资源 Id</param>
/// <param name="property">附加属性参数</param>
/// <returns></returns>
public static async Task StartResource(string resourceId, Dictionary<string, object> property)

/// <summary>
/// resource 结束
/// </summary>
/// <param name="resourceId">资源 Id</param>
/// <returns></returns>
public static async Task StopResource(string resourceId)

/// <summary>
/// resource 结束
/// </summary>
/// <param name="resourceId">资源 Id</param>
/// <param name="property">附加属性参数</param>
public static async Task StopResource(string resourceId, Dictionary<string, object> property)


/// <summary>
/// 添加网络传输内容和指标
/// </summary>
/// <param name="resourceId">资源 Id</param>
/// <param name="resourceParams">数据传输内容</param>
/// <param name="netStatus">网络指标数据</param>
public static async Task AddResource(string resourceId, ResourceParams resourceParams)

FTUnityBridge.StartResource(resourceId);

FTUnityBridge.StopResource(resourceId);

ResourceParams resourceParams = new ResourceParams();
resourceParams.url = url;
resourceParams.requestHeader = client.DefaultRequestHeaders.ToDictionary(header => header.Key, header => string.Join(",", header.Value));
resourceParams.responseHeader = response.Headers.ToDictionary(header => header.Key, header => string.Join(",", header.Value));
resourceParams.resourceStatus = (int)response.StatusCode;
resourceParams.responseBody = responseData;
resourceParams.resourceMethod = "GET";

FTUnityBridge.AddResource(resourceId, resourceParams);

/// <summary>
/// 添加错误信息
/// </summary>
/// <param name="log">日志</param>
/// <param name="message">消息</param>
/// <param name="errorType">错误类型</param>
/// <param name="state">程序运行状态</param>
/// <returns></returns>
public static async Task AddError(string log, string message)


/// <summary>
/// 添加错误信息
/// </summary>
/// <param name="log">日志</param>
/// <param name="message">消息</param>
/// <param name="errorType">错误类型</param>
/// <param name="state">程序运行状态</param>
/// <param name="property">附加属性参数</param>
/// <returns></returns>
public static async Task AddError(string log, string message,
    Dictionary<string, object> property)

void OnEnable()
{
    Application.logMessageReceived += LogCallBack;

}

void OnDisable()
{
    Application.logMessageReceived -= LogCallBack;
}

void LogCallBack(string condition, string stackTrace, LogType type)
{
    if (type == LogType.Exception)
    {
        FTUnityBridge.AddError(stackTrace, condition);
    }

}

/// <summary>
/// 添加长耗时任务
/// </summary>
/// <param name="log">日志内容</param>
/// <param name="duration">持续时间，纳秒</param>
/// <returns></returns>
public static async Task AddLongTask(string log, long duration)

/// <summary>
/// 添加长耗时任务
/// </summary>
/// <param name="log">日志内容</param>
/// <param name="duration">持续时间，纳秒</param>
/// <param name="property">附加属性参数</param>
/// <returns></returns>
public static async Task AddLongTask(string log, long duration, Dictionary<string, object> property)

FTUnityBridge.AddLongTask("long task test", 100002);

/// <summary>
/// 添加日志
/// </summary>
/// <param name="log">日志内容</param>
/// <param name="level">日志等级 info，warning，error，critical，ok</param>
/// <returns></returns>
public static async Task AddLog(string log, LogLevel level)

 /// <summary>
/// 添加日志
/// </summary>
/// <param name="log">日志内容</param>
/// <param name="level">日志等级 info，warning，error，critical，ok</param>
/// <param name="property">附加属性参数</param>
/// <returns></returns>
public static async Task AddLog(string log, LogLevel level, Dictionary<string, object> property)

FTUnityBridge.AddLog("test log", "test message");

/// <summary>
/// 获取链路 Id
/// </summary>
/// <param name="url">url 地址</param>
/// <returns>json 字符</returns>
public static async Task<string> GetTraceHeaderWithUrl(string url)


/// <summary>
/// 获取链路
/// </summary>
/// <param name="resourceId">资源 Id</param>
/// <param name="url">url 地址</param>
/// <returns>json 字符</returns>
public static async Task<string> GetTraceHeader(string resourceId, string url)

string headData = FTUnityBridge.GetTraceHeader(resourceId, FAKE_URL);

string headData = FTUnityBridge.GetTraceHeader(FAKE_URL);

/**
 * 清除所有尚未上传至服务器的数据。
*/
FTUnityBridge.clearAllData();

/**
 * 主动同步数据，当配置 `FTMobileConfig.autoSync=false` 时,需要主动触发本方法，进行数据同步。
 * @returns a Promise.
 */
FTUnityBridge.flushSyncData();

/// <summary>
/// 添加自定义全局参数。作用于 RUM、Log 数据
/// </summary>
public static void AppendGlobalContext(Dictionary<string, object> property)

/// <summary>
/// 添加自定义 RUM 全局参数。作用于 RUM 数据
/// </summary>
public static void AppendRUMGlobalContext(Dictionary<string, object> property)

/// <summary>
/// 添加自定义 RUM、Log 全局参数。作用于 Log 数据
/// </summary>
public static void AppendLogGlobalContext(Dictionary<string, object> property)

/// <summary>
/// 绑定 RUM 用户信息
/// </summary>
/// <param name="userId">用户唯一id</param>
public static async Task BindUserData(string userId)

/// <summary>
/// 绑定 RUM 用户信息
/// </summary>
/// <param name="userData"></param>
public static async Task BindUserData(UserData userData)

FTUnityBridge.BindUserData(new UserData
            {
                userId = "userid",
                userName = "userName",
                userEmail = "someone@email.com",
                extra = new Dictionary<string, string>{
                    {"custom_data","custom data"}
                }
            });

FTUnityBridge.UnBindUserdata()

/// <summary>
/// SDK 释放
/// </summary>

FTUnityBridge.DeInit()

  FTUnityBridge.Install(new SDKConfig
    {
        //...
        dataModifier = new Dictionary<string, object>{
            {"device_uuid","xxx"}
        },
        lineDataModifier = new Dictionary<string, Dictionary<string, object>>
        {
            {"view",new Dictionary<string, object>{
                {"view_url","xxx"}
                }
            }
        }
    });

// FTSDK.cs
IEnumerator _LoadPrefabs()
{
    yield return Instantiate(MainThreadDispatch);
    //_InitSDK();                                 // 取消初始化
    yield return Instantiate(ViewObserver);
}
