K8s 로그 수집을 위한 Logback Socket 모범 사례¶

      [[inputs.logging]]
        ## required
        #  logfiles = [
        #    "/var/log/syslog",
        #    "/var/log/message",
        #  ]
          # only two protocols are supported:TCP and UDP
          sockets = [
                  "tcp://0.0.0.0:9541",
          #      "udp://0.0.0.0:9531",
          ]
          ## glob filteer
          ignore = [""]

          ## your logging source, if it's empty, use 'default'
          source = "socket_log"

          ## add service tag, if it's empty, use $source.
          service = "socket_service"

          ## grok pipeline script name
          pipeline = "logback_socket_pipeline.p"

          ## optional status:
          ##   "emerg","alert","critical","error","warning","info","debug","OK"
          ignore_status = []

          ## optional encodings:
          ##    "utf-8", "utf-16le", "utf-16le", "gbk", "gb18030" or ""
          character_encoding = ""

          ## The pattern should be a regexp. Note the use of '''this regexp'''
          ## regexp link: [https://golang.org/pkg/regexp/syntax/#hdr-Syntax](https://golang.org/pkg/regexp/syntax/#hdr-Syntax)
          # multiline_match = '''^\S'''

          ## removes ANSI escape codes from text strings
          remove_ansi_escape_codes = false

          [inputs.logging.tags]
            service = "socket-demo"

        #------------------------------------   警告   -------------------------------------**
        # 不要修改本文件，如果要更新，请拷贝至其它文件，最好以某种前缀区分，避免重启后被覆盖**
        #-----------------------------------------------------------------------------------        **
        # access log**
        json(_,msg,"message")**
        json(_,class,"class")**
        json(_,appName,"service")**
        json(_,thread,"thread")**
        json(_,severity,"status")**
        json(_,trace,"trace_id")**
        json(_,span,"span_id")**
        json(_,`@timestamp`,"time")**
        default_time(time)**

apiVersion: v1
kind: Namespace
metadata:
  name: datakit
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: datakit
rules:
  - apiGroups:
      - rbac.authorization.k8s.io
    resources:
      - clusterroles
    verbs:
      - get
      - list
      - watch
  - apiGroups:
      - ""
    resources:
      - nodes
      - nodes/proxy
      - namespaces
      - pods
      - pods/log
      - events
      - services
      - endpoints
      - ingresses
    verbs:
      - get
      - list
      - watch
  - apiGroups:
      - apps
    resources:
      - deployments
      - daemonsets
      - statefulsets
      - replicasets
    verbs:
      - get
      - list
      - watch
  - apiGroups:
      - batch
    resources:
      - jobs
      - cronjobs
    verbs:
      - get
      - list
      - watch
  - apiGroups:
      - metrics.k8s.io
    resources:
      - pods
      - nodes
    verbs:
      - get
      - list
  - nonResourceURLs: ["/metrics"]
    verbs: ["get"]

---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: datakit
  namespace: datakit

---
apiVersion: v1
kind: Service
metadata:
  name: datakit-service
  namespace: datakit
spec:
  selector:
    app: daemonset-datakit
  ports:
    - protocol: TCP
      port: 9529
      targetPort: 9529

---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: datakit
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: datakit
subjects:
  - kind: ServiceAccount
    name: datakit
    namespace: datakit

---
apiVersion: apps/v1
kind: DaemonSet
metadata:
  labels:
    app: daemonset-datakit
  name: datakit
  namespace: datakit
spec:
  revisionHistoryLimit: 10
  selector:
    matchLabels:
      app: daemonset-datakit
  template:
    metadata:
      labels:
        app: daemonset-datakit
      annotations:
        datakit/logs: |
          [
            {
              "disable": true
            }
          ]
    spec:
      hostNetwork: true
      dnsPolicy: ClusterFirstWithHostNet
      containers:
        - env:
            - name: HOST_IP
              valueFrom:
                fieldRef:
                  apiVersion: v1
                  fieldPath: status.hostIP
            - name: NODE_NAME
              valueFrom:
                fieldRef:
                  apiVersion: v1
                  fieldPath: spec.nodeName
            - name: ENV_DATAWAY
              value: https://openway.guance.com?token=<you token>
            - name: ENV_GLOBAL_HOST_TAGS
              value: host=__datakit_hostname,host_ip=__datakit_ip,cluster_name=k8s-dev
            - name: ENV_DEFAULT_ENABLED_INPUTS
              value: cpu,disk,diskio,mem,swap,system,hostobject,net,host_processes,container,statsd,ddtrace
            - name: ENV_ENABLE_ELECTION
              value: enable
            - name: ENV_HTTP_LISTEN
              value: 0.0.0.0:9529
            - name: ENV_LOG_LEVEL
              value: info
          image: pubrepo.guance.com/datakit/datakit:1.2.6
          imagePullPolicy: IfNotPresent
          name: datakit
          ports:
            - containerPort: 9529
              hostPort: 9529
              name: port
              protocol: TCP
          securityContext:
            privileged: true
          volumeMounts:
            - mountPath: /var/run/docker.sock
              name: docker-socket
              readOnly: true
            - mountPath: /usr/local/datakit/conf.d/container/container.conf
              name: datakit-conf
              subPath: container.conf
            #- mountPath: /usr/local/datakit/conf.d/log/logging.conf
            #  name: datakit-conf
            #  subPath: logging.conf
            - mountPath: /usr/local/datakit/pipeline/demo_system.p
              name: datakit-conf
              subPath: log_demo_system.p
            - mountPath: /usr/local/datakit/conf.d/log/logging-socket-demo.conf
              name: datakit-conf
              subPath: logging-socket-demo.conf
            - mountPath: /usr/local/datakit/pipeline/logback_socket_pipeline.p
              name: datakit-conf
              subPath: logback_socket_pipeline.p
            - mountPath: /host/proc
              name: proc
              readOnly: true
            - mountPath: /host/dev
              name: dev
              readOnly: true
            - mountPath: /host/sys
              name: sys
              readOnly: true
            - mountPath: /rootfs
              name: rootfs
            - mountPath: /sys/kernel/debug
              name: debugfs
          workingDir: /usr/local/datakit
      hostIPC: true
      hostPID: true
      restartPolicy: Always
      serviceAccount: datakit
      serviceAccountName: datakit
      volumes:
        - configMap:
            name: datakit-conf
          name: datakit-conf
        - hostPath:
            path: /var/run/docker.sock
          name: docker-socket
        - hostPath:
            path: /proc
            type: ""
          name: proc
        - hostPath:
            path: /dev
            type: ""
          name: dev
        - hostPath:
            path: /sys
            type: ""
          name: sys
        - hostPath:
            path: /
            type: ""
          name: rootfs
        - hostPath:
            path: /sys/kernel/debug
            type: ""
          name: debugfs
  updateStrategy:
    rollingUpdate:
      maxUnavailable: 1
    type: RollingUpdate
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: datakit-conf
  namespace: datakit
data:
  #### container
  container.conf: |-
    [inputs.container]
      docker_endpoint = "unix:///var/run/docker.sock"
      containerd_address = "/var/run/containerd/containerd.sock"

      enable_container_metric = true
      enable_k8s_metric = true
      enable_pod_metric = true

      ## Containers logs to include and exclude, default collect all containers. Globs accepted.
      container_include_log = []
      container_exclude_log = ["image:pubrepo.guance.com/datakit/logfwd*", "image:pubrepo.guance.com/datakit/datakit*"]

      exclude_pause_container = true

      ## Removes ANSI escape codes from text strings
      logging_remove_ansi_escape_codes = false

      kubernetes_url = "https://kubernetes.default:443"

      ## Authorization level:
      ##   bearer_token -> bearer_token_string -> TLS
      ## Use bearer token for authorization. ('bearer_token' takes priority)
      ## linux at:   /run/secrets/kubernetes.io/serviceaccount/token
      ## windows at: C:\var\run\secrets\kubernetes.io\serviceaccount\token
      bearer_token = "/run/secrets/kubernetes.io/serviceaccount/token"
      # bearer_token_string = "<your-token-string>"

      [inputs.container.tags]
        # some_tag = "some_value"
        # more_tag = "some_other_value"

  #### logging
  logging.conf: |-
    [[inputs.logging]]
      ## required
      logfiles = [
        "/rootfs/var/log/k8s/ruoyi-system/info.log",
        "/rootfs/var/log/k8s/ruoyi-system/error.log",
      ]

      ## glob filteer
      ignore = [""]

      ## your logging source, if it's empty, use 'default'
      source = "k8s-demo-system1"

      ## add service tag, if it's empty, use $source.
      service = "k8s-demo-system1"

      ## grok pipeline script path
      pipeline = "demo_system.p"

      ## optional status:
      ##   "emerg","alert","critical","error","warning","info","debug","OK"
      ignore_status = []

      ## optional encodings:
      ##    "utf-8", "utf-16le", "utf-16le", "gbk", "gb18030" or ""
      character_encoding = ""

      ## The pattern should be a regexp. Note the use of '''this regexp'''
      ## regexp link: https://golang.org/pkg/regexp/syntax/#hdr-Syntax
      multiline_match = '''^\d{4}-\d{2}-\d{2}'''

      [inputs.logging.tags]
      # some_tag = "some_value"
      # more_tag = "some_other_value"

  #### system-log
  log_demo_system.p: |-
    #日志样式
    #2021-06-25 14:27:51.952 [http-nio-9201-exec-7] INFO  c.r.s.c.SysUserController - [list,70] ruoyi-08-system 5430221015886118174 6503455222153372731 - 查询用户

    grok(_, "%{TIMESTAMP_ISO8601:time} %{NOTSPACE:thread_name} %{LOGLEVEL:status}%{SPACE}%{NOTSPACE:class_name} - \\[%{NOTSPACE:method_name},%{NUMBER:line}\\] - %{DATA:service_name} %{DATA:trace_id} %{DATA:span_id} - %{GREEDYDATA:msg}")

    default_time(time,"Asia/Shanghai")

  logback_socket_pipeline.p: |-
    #------------------------------------   警告   -------------------------------------
    # 不要修改本文件，如果要更新，请拷贝至其它文件，最好以某种前缀区分，避免重启后被覆盖
    #-----------------------------------------------------------------------------------
    # access log
    json(_,msg,"message")
    json(_,class,"class")
    json(_,appName,"service")
    json(_,thread,"thread")
    json(_,severity,"status")
    json(_,trace,"trace_id")
    json(_,span,"span_id")
    json(_,`@timestamp`,"time")
    default_time(time)

  logging-socket-demo.conf: |-
    [[inputs.logging]]
      ## required
    #  logfiles = [
    #    "/var/log/syslog",
    #    "/var/log/message",
    #  ]
      # only two protocols are supported:TCP and UDP
      sockets = [
            "tcp://0.0.0.0:9541",
      #      "udp://0.0.0.0:9531",
      ]
      ## glob filteer
      ignore = [""]

      ## your logging source, if it's empty, use 'default'
      source = "socket_log"

      ## add service tag, if it's empty, use $source.
      service = "socket_service"

      ## grok pipeline script name
      pipeline = "logback_socket_pipeline.p"

      ## optional status:
      ##   "emerg","alert","critical","error","warning","info","debug","OK"
      ignore_status = []

      ## optional encodings:
      ##    "utf-8", "utf-16le", "utf-16le", "gbk", "gb18030" or ""
      character_encoding = ""

      ## The pattern should be a regexp. Note the use of '''this regexp'''
      ## regexp link: https://golang.org/pkg/regexp/syntax/#hdr-Syntax
      # multiline_match = '''^\S'''

      ## removes ANSI escape codes from text strings
      remove_ansi_escape_codes = false

      [inputs.logging.tags]
        service = "sign"

<!-- 对日志进行了json序列化处理，dk支持文本格式的日志，可以通过socket直接推送过去-->
    <appender name="socket" class="net.logstash.logback.appender.LogstashTcpSocketAppender">
        <!-- datakit host: logsocket_port -->
        <destination>${dkSocketHost}:${dkSocketPort}</destination>
        <!-- 日志输出编码 -->
        <encoder class="net.logstash.logback.encoder.LoggingEventCompositeJsonEncoder">
            <providers>
                <timestamp>
                    <timeZone>UTC+8</timeZone>
                </timestamp>
                <pattern>
                        <pattern>
                            {
                            "severity": "%level",
                            "appName": "${logName:-}",
                            "trace": "%X{dd.trace_id:-}",
                            "span": "%X{dd.span_id:-}",
                            "pid": "${PID:-}",
                            "thread": "%thread",
                            "class": "%logger{40}",
                            "msg": "%message\n%exception"
                            }
                        </pattern>
                </pattern>
            </providers>
        </encoder>
    </appender>

<root level="info">
    <!-- socket appender -->
    <appender-ref ref="socket" />
</root>

<?xml version="1.0" encoding="UTF-8"?>
<configuration scan="true" scanPeriod="30 seconds">
    <!-- 部分参数需要来源于properties文件 -->
    <springProperty scope="context" name="logName" source="spring.application.name" defaultValue="localhost.log"/>
    <springProperty scope="context" name="dkSocketHost" source="datakit.socket.host" />
    <springProperty scope="context" name="dkSocketPort" source="datakit.socket.port" />
    <!-- 配置后可以动态修改日志级别-->
    <jmxConfigurator />
    <property name="log.pattern" value="%d{yyyy-MM-dd HH:mm:ss.SSS} [%thread] %-5level %logger{20} - [%method,%line] %X{dd.service} %X{dd.trace_id} %X{dd.span_id} - %msg%n" />

    <!-- %m输出的信息,%p日志级别,%t线程名,%d日期,%c类的全名,,,, -->
    <appender name="STDOUT" class="ch.qos.logback.core.ConsoleAppender">
        <encoder>
            <pattern>${log.pattern}</pattern>
            <charset>UTF-8</charset>
        </encoder>
    </appender>

    <appender name="FILE" class="ch.qos.logback.core.rolling.RollingFileAppender">
        <file>logs/${logName}/${logName}.log</file>    <!-- 使用方法 -->
        <append>true</append>
        <rollingPolicy class="ch.qos.logback.core.rolling.SizeAndTimeBasedRollingPolicy">
            <fileNamePattern>logs/${logName}/${logName}-%d{yyyy-MM-dd}.log.%i</fileNamePattern>
            <maxFileSize>64MB</maxFileSize>
            <maxHistory>30</maxHistory>
            <totalSizeCap>1GB</totalSizeCap>
        </rollingPolicy>
        <encoder>
            <pattern>${log.pattern}</pattern>
            <charset>UTF-8</charset>
        </encoder>
    </appender>

    <!-- 对日志进行了json序列化处理，dk支持文本格式的日志，可以通过socket直接推送过去-->
    <appender name="socket" class="net.logstash.logback.appender.LogstashTcpSocketAppender">
        <!-- datakit host: logsocket_port -->
        <destination>${dkSocketHost}:${dkSocketPort}</destination>
        <!-- 日志输出编码 -->
        <encoder class="net.logstash.logback.encoder.LoggingEventCompositeJsonEncoder">
            <providers>
                <timestamp>
                    <timeZone>UTC+8</timeZone>
                </timestamp>
                <pattern>
                        <pattern>
                            {
                            "severity": "%level",
                            "appName": "${logName:-}",
                            "trace": "%X{dd.trace_id:-}",
                            "span": "%X{dd.span_id:-}",
                            "pid": "${PID:-}",
                            "thread": "%thread",
                            "class": "%logger{40}",
                            "msg": "%message\n%exception"
                            }
                        </pattern>
                </pattern>
            </providers>
        </encoder>
    </appender>


    <!-- 只打印error级别的内容 -->
    <logger name="com.netflix" level="ERROR" />
    <logger name="net.sf.json" level="ERROR" />
    <logger name="org.springframework" level="ERROR" />
    <logger name="springfox" level="ERROR" />

    <!-- sql 打印 配置-->
    <logger name="com.github.pagehelper.mapper" level="DEBUG" />
    <logger name="org.apache.ibatis" level="DEBUG" />

    <root level="info">
        <appender-ref ref="STDOUT" />
        <appender-ref ref="FILE" />
        <appender-ref ref="socket" />
    </root>
</configuration>

apiVersion: v1
kind: Service
metadata:
  name: logback-socket-service
  labels:
    app: logback-socket-service
spec:
  selector:
    app: logback-socket-service
  ports:
    - protocol: TCP
      port: 8080
      nodePort: 32100
      targetPort: 8080
  type: NodePort
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: logback-socket-service
  labels:
    app: logback-socket-service
spec:
  replicas: 1
  selector:
    matchLabels:
      app: logback-socket-service
  template:
    metadata:
      labels:
        app: logback-socket-service
    spec:
      nodeName: master
      containers:
        - env:
            - name: POD_NAME
              valueFrom:
                fieldRef:
                  fieldPath: metadata.name
            - name: DATAKIT_SOCKET_PORT
              value: "9541"
            - name: JAVA_OPTS
              value: |-
                -javaagent:/usr/dd-java-agent/agent/dd-java-agent.jar -Ddd.service.name=demo-k8s-logback-socket  -Ddd.tags=container_host:$(PODE_NAME) -Ddd.service.mapping=mysql:mysql-k8s,redis:redisk8s -Ddd.env=dev -Ddd.agent.port=9529
            - name: PARAMS
              value: "--datakit.socket.host=$(DD_AGENT_HOST) --datakit.socket.port=$(DATAKIT_SOCKET_PORT)"
            - name: DD_AGENT_HOST
              valueFrom:
                fieldRef:
                  apiVersion: v1
                  fieldPath: status.hostIP
          name: logback-socket-service
          image: registry.cn-shenzhen.aliyuncs.com/lr_715377484/springboot-logback-socket-appender-demo:v1
          #command: ["sh","-c"]
          ports:
            - containerPort: 8080
              protocol: TCP
          volumeMounts:
            - name: ddagent
              mountPath: /usr/dd-java-agent/agent
          resources:
            limits:
              memory: 512Mi
            requests:
              memory: 256Mi
      initContainers:
        - command:
          - sh
          - -c
          - set -ex;mkdir -p /ddtrace/agent;cp -r /datadog-init/* /ddtrace/agent;
          image: pubrepo.guance.com/datakit-operator/dd-lib-java-init
          imagePullPolicy: Always
          name: ddtrace-agent-sidecar
          volumeMounts:
            - mountPath: /ddtrace/agent
              name: ddagent
      restartPolicy: Always
      volumes:
        - name: ddagent
          emptyDir: {}
