Pod 로그 수집 모범 사례¶

apiVersion: apps/v1
kind: Deployment
metadata:
  name: log-fwd-deployment
spec:
  replicas: 1
  selector:
    matchLabels:
      app: log-fwd-pod
  template:
    metadata:
      labels:
        app: log-fwd-pod
      annotations:
    spec:
      nodeName: k8s-node2
      containers:
        - name: log-fwd-container
          image: 172.16.0.238/df-demo/log-demo-service:v2
          ports:
            - containerPort: 8090
              protocol: TCP
          volumeMounts:
            - mountPath: /data/app/logs
              name: varlog
        - name: logfwd
          image: pubrepo.guance.com/datakit/logfwd:1.2.12
          env:
            - name: LOGFWD_DATAKIT_HOST
              valueFrom:
                fieldRef:
                  apiVersion: v1
                  fieldPath: status.hostIP
            - name: LOGFWD_DATAKIT_PORT
              value: "9531"
            - name: LOGFWD_ANNOTATION_DATAKIT_LOGS
              valueFrom:
                fieldRef:
                  apiVersion: v1
                  fieldPath: metadata.annotations['datakit/logs']
            - name: LOGFWD_POD_NAME
              valueFrom:
                fieldRef:
                  apiVersion: v1
                  fieldPath: metadata.name
            - name: LOGFWD_POD_NAMESPACE
              valueFrom:
                fieldRef:
                  apiVersion: v1
                  fieldPath: metadata.namespace
          volumeMounts:
            - mountPath: /var/log
              name: varlog
            - mountPath: /opt/logfwd/config
              name: logfwd-config
              subPath: config
      restartPolicy: Always
      volumes:
        - name: varlog
          emptyDir: {}
        - configMap:
            name: logfwd-conf
          name: logfwd-config
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: logfwd-conf
data:
  config: |
    [
        {
            "loggings": [
                {
                    "logfiles": ["/var/log/log.log"],
                    "source": "log_fwd_demo",
                    "pipeline": "pod-logging-demo.p",
                    "multiline_match": "^\\d{4}-\\d{2}-\\d{2}",
                    "tags": {
                        "flag": "tag1"
                    }
                }
            ]
        }
    ]

<?xml version="1.0" encoding="UTF-8"?>

<configuration scan="true" scanPeriod="60 seconds" debug="false">
    <contextName>logback</contextName>

    <!-- 로그 루트 디렉터리 - -
    <property name="log.root.dir" value="./logs"/>
    <!-- 로그 출력 형식 - -
    <property name="log.pattern" value="%d{yyyy-MM-dd HH:mm:ss.SSS} [%thread] %-5level %logger{20} - [%method,%line] -  - %msg%n" />

    <!-- 콘솔에 로그 출력 - -
    <appender name="Console" class="ch.qos.logback.core.ConsoleAppender">
        <encoder>
            <pattern>${log.pattern}</pattern>
        </encoder>
    </appender>

    <root level="INFO">
        <appender-ref ref="Console"/>
    </root>
</configuration>

apiVersion: v1
kind: Service
metadata:
  name: log-demo-service
  labels:
    app: log-demo-service
spec:
  selector:
    app: log-demo-service
  ports:
    - protocol: TCP
      port: 8090
      nodePort: 30053
      targetPort: 8090
  type: NodePort
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: log-demo-service
  labels:
    app: log-demo-service
spec:
  replicas: 1
  selector:
    matchLabels:
      app: log-demo-service
  template:
    metadata:
      labels:
        app: log-demo-service
      annotations:
        datakit/logs: |
          [
            {
              "source": "pod-logging-testing-demo",
              "service": "pod-logging-testing-demo",
              "pipeline": "pod-logging-demo.p",
              "multiline_match": "^\\d{4}-\\d{2}-\\d{2}"
            }
          ]

    spec:
      containers:
        - env:
            - name: POD_NAME
              valueFrom:
                fieldRef:
                  fieldPath: metadata.name
          name: log-service
          image: <your-harbor>/log-demo-service:v1
          ports:
            - containerPort: 8090
              protocol: TCP

      restartPolicy: Always
      volumes:
        - name: ddagent
          emptyDir: {}
