Kubernetes クラスターにおけるログ収集のさまざまな方法¶

        - name: ENV_LOG_LEVEL
          value: debug

    - name: ENV_LOG
      value: stdout
    - name: ENV_GIN_LOG
      value: stdout

kubectl logs datakit-2fnrz -n datakit #

        - name: ENV_DEFAULT_ENABLED_INPUTS
          value: cpu,disk,diskio,mem,swap,system,hostobject,net,host_processes,container

  container_include_log = []  # 相当于image:*
  container_exclude_log = ["image:pubrepo.guance.com/datakit/logfwd*"]

apiVersion: apps/v1
kind: Deployment
metadata:
  name: log-demo-service
  labels:
    app: log-demo-service
spec:
  replicas: 1
  selector:
    matchLabels:
      app: log-demo-service
  template:
    metadata:
      labels:
        app: log-demo-service
      annotations:
        # 以下を追加
        datakit/logs: |
          [
            {
              "source": "pod-logging-testing-demo",
              "service": "pod-logging-testing-demo",
              "pipeline": "pod-logging-demo.p",
              "multiline_match": "^\\d{4}-\\d{2}-\\d{2}"
            }
          ]

apiVersion: apps/v1
kind: Deployment
metadata:

...

spec:
  ...
  template:
    metadata:
      annotations:
        ## 以下を追加
        datakit/logs: |
          [
            {
              "disable": true
            }
          ]

java ${JAVA_OPTS}   -jar ${jar} ${PARAMS}  2>&1 > /dev/null

---
apiVersion: v1
kind: ConfigMap
metadata:
  name: datakit-conf
  namespace: datakit
data:
    #### container
    container.conf: |-
      [inputs.container]
        docker_endpoint = "unix:///var/run/docker.sock"
        containerd_address = "/var/run/containerd/containerd.sock"

        enable_container_metric = true
        enable_k8s_metric = true
        enable_pod_metric = true

        ## Containers logs to include and exclude, default collect all containers. Globs accepted.
        container_include_log = []
        container_exclude_log = ["image:pubrepo.guance.com/datakit/logfwd*", "image:pubrepo.guance.com/datakit/datakit*"]

        exclude_pause_container = true

        ## Removes ANSI escape codes from text strings
        logging_remove_ansi_escape_codes = false

        kubernetes_url = "https://kubernetes.default:443"

        ## Authorization level:
        ##   bearer_token -> bearer_token_string -> TLS
        ## Use bearer token for authorization. ('bearer_token' takes priority)
        ## linux at:   /run/secrets/kubernetes.io/serviceaccount/token
        ## windows at: C:\var\run\secrets\kubernetes.io\serviceaccount\token
        bearer_token = "/run/secrets/kubernetes.io/serviceaccount/token"
        # bearer_token_string = "<your-token-string>"

        [inputs.container.tags]
          # some_tag = "some_value"
          # more_tag = "some_other_value"

        volumeMounts:
        - mountPath: /usr/local/datakit/conf.d/container/container.conf
          name: datakit-conf
          subPath: container.conf

        container_include_log = ["image:*log-order*"]
        container_exclude_log = ["image:*log-pay*"]

<?xml version="1.0" encoding="UTF-8"?>

<configuration scan="true" scanPeriod="60 seconds" debug="false">
    <springProperty scope="context" name="dkSocketHost" source="datakit.socket.host" />
    <springProperty scope="context" name="dkSocketPort" source="datakit.socket.port" />
    <contextName>logback</contextName>

    <!-- ログルートディレクトリ -->
    <property name="log.path" value="./logs"/>
    <!-- ログ出力形式 -->
    <property name="log.pattern" value="%d{yyyy-MM-dd HH:mm:ss.SSS} [%thread] %-5level %logger{20} - [%method,%line] -  - %msg%n" />

    <!-- コンソールにログを出力 -->
    <appender name="Console" class="ch.qos.logback.core.ConsoleAppender">
        <encoder>
            <pattern>${log.pattern}</pattern>
        </encoder>
    </appender>
    ...
    <!-- 以下は追加する Socket appender -->
    <appender name="socket" class="net.logstash.logback.appender.LogstashTcpSocketAppender">
        <!-- datakit host: logsocket_port -->
        <destination>${dkSocketHost}:${dkSocketPort}</destination>
        <!-- ログ出力エンコーディング -->
        <encoder class="net.logstash.logback.encoder.LoggingEventCompositeJsonEncoder">
            <providers>
                <timestamp>
                    <timeZone>UTC+8</timeZone>
                </timestamp>
                <pattern>
                    <pattern>
                        {
                        "severity": "%level",
                        "appName": "${logName:-}",
                        "trace": "%X{dd.trace_id:-}",
                        "span": "%X{dd.span_id:-}",
                        "pid": "${PID:-}",
                        "thread": "%thread",
                        "class": "%logger{40}",
                        "msg": "%message\n%exception"
                        }
                    </pattern>
                </pattern>
            </providers>
        </encoder>
    </appender>
    <root level="INFO">
        <appender-ref ref="Console"/>
        <appender-ref ref="file_info"/>
        <appender-ref ref="socket" />
    </root>
</configuration>

datakit:
  socket:
    host: 120.26.218.200  #
    port: 9542

<dependency>
    <groupId>net.logstash.logback</groupId>
    <artifactId>logstash-logback-encoder</artifactId>
    <version>4.9</version>
</dependency>

        volumeMounts:  # この位置に以下の3行を追加
        - mountPath: /usr/local/datakit/conf.d/log/logging-socket.conf
          name: datakit-conf
          subPath: logging-socket.conf

---
apiVersion: v1
kind: ConfigMap
metadata:
  name: datakit-conf
  namespace: datakit
data:
    logging-socket.conf: |-
      [[inputs.logging]]
        # only two protocols are supported:TCP and UDP
        sockets = [
          "tcp://0.0.0.0:9542",
        #"udp://0.0.0.0:9531",
        ]
        ignore = [""]
        source = "demo-socket-service"
        service = ""
        pipeline = ""
        ignore_status = []
        character_encoding = ""
        # multiline_match = '''^\S'''
        remove_ansi_escape_codes = false

        [inputs.logging.tags]
        # some_tag = "some_value"
        # more_tag = "some_other_value"

cd /usr/local/datakit/conf.d/log
cp logging.conf.sample  logging.conf

        volumeMounts:
        - name: app-log
          mountPath: /data/app/logs/demo-system

      ...

      volumes:
      - name: app-log
        hostPath:
          path: /var/log/k8s/demo-system

        volumeMounts:  # この位置に以下の3行を追加
        - mountPath: /usr/local/datakit/conf.d/log/logging.conf
          name: datakit-conf
          subPath: logging.conf

---
apiVersion: v1
kind: ConfigMap
metadata:
  name: datakit-conf
  namespace: datakit
data:
    #### logging
    logging.conf: |-
        [[inputs.logging]]
          ## required
          logfiles = [
            "/rootfs/var/log/k8s/demo-system/info.log",
          ]

          ## glob filteer
          ignore = [""]

          ## your logging source, if it's empty, use 'default'
          source = "k8s-demo-system-log"

          ## add service tag, if it's empty, use $source.
          #service = "k8s-demo-system-log"

          ## grok pipeline script path
          pipeline = ""
          ## optional status:
          ##   "emerg","alert","critical","error","warning","info","debug","OK"
          ignore_status = []

          ## optional encodings:
          ##    "utf-8", "utf-16le", "utf-16le", "gbk", "gb18030" or ""
          character_encoding = ""

          ## The pattern should be a regexp. Note the use of '''this regexp'''
          ## regexp link: https://golang.org/pkg/regexp/syntax/#hdr-Syntax
          multiline_match = '''^\d{4}-\d{2}-\d{2}'''

          [inputs.logging.tags]
          # some_tag = "some_value"
          # more_tag = "some_other_value"
