Create Detection Rules¶

Enter Security Monitoring > Security Incident Management > Create to start creating.

Basic Settings¶

Detection Frequency¶

The rule will run once according to the time interval set here (such as every 5 minutes, every 1 hour). Options include the last 1 minute, last 5 minutes, last 15 minutes, last 30 minutes, last 1 hour, last 6 hours, last 12 hours, and last 24 hours.

In addition to the specific options provided by the system, you can also enter a custom crontab task configured based on minutes, hours, days, months, and weeks for scheduled task execution.

Detection Interval¶

This indicates the time range of data queries each time the task is executed. The selectable detection intervals are affected by the detection frequency.

Define Detection Rules¶

When defining security detection logic, you can use DQL in scripts to query data and set signal trigger logic through conditional expressions (e.g., field matching, threshold judgment).

When writing rules manually, you can:

• Enable automatic text wrapping or content overflow;
• Use shortcuts to format content;
• Copy with one click;
• Write script content directly in the content box;
• Select fx functions;
• Test scripts;
• Edit scripts in full screen.

Example:

# data1,ok = dql("T::re(`.*`):(avg(duration), service, span_id, status) by host limit 1")
# #data2 = dql("T::re(`.*`):(max(duration), service, span_id, status) by host limit 2")


# #result:Detection result, required, type basic type (string, integer, float)
# #result = data1.avg(duration)

# #dimension_tags:Detection object, optional, type map
# #dimension_tags = {"host":data1['series'][0][0]['tags']['host']}

# #status:Level, optional, type enumeration, if defined here has priority over user-defined level on the page
# #Options: critical, high, medium, low, info
# status = "high"

# #extra_data:Additional attributes, optional, type map
# #related_data = {"service":"wwwww"}
# #related_data = {"service":data1['series'][0][0]['columns']['service'],
#                # "span_id":data1['series'][0][0]['columns']['span_id'],
#                # "status":data1['series'][0][0]['columns']['status']}


# #fn trigger(result: int|float|bool|str, level: str = "", dim_tags: map = {}, related_data: map = {})
# #trigger(data1,status,dimension_tags,related_data)
# host = dql_series_get(data1,"host")
# service = dql_series_get(data1,"service")
# status = dql_series_get(data1,"status")
# trigger(data1,status,dimension_tags={"host":host},related_data={"service":service,"status":status})



data1 = dql("T::re(`.*`):(avg(duration), service, span_id, status) by host limit 1")
status = "high"
host = dql_series_get(data1,"host")
#printf("%v", {"host": host_o})
#host_info = dql_series_get(host_o,"host")
#printf("%v", {"host": host_info})
service = dql_series_get(data1,"service")
span_id = dql_series_get(data1,"span_id")

trigger(data1,status,dimension_tags={"host":host[0][0]},related_data={"service":service,"span_id":span_id})

In the above script example, it mainly consists of three parts:

1. Data Query: Using DQL to query all {{ Metrics }} (re(.*)), calculate the average value of the duration field grouped by each host, while returning service, span_id, and status fields. limit 1 means only 1 result will be returned;

2. Data Processing:

   host = dql_series_get(data1,"host")  # Extract the `host` field from the query results
   service = dql_series_get(data1,"service") # Extract the `service` field
   span_id = dql_series_get(data1,"span_id") # Extract the `span_id` field


   3. Alert Triggering:

trigger(data1,status,dimension_tags={"host":host[0][0]},related_data={"service":service,"span_id":span_id})

Security Level¶

Select the security level for the current monitoring rule:

Configure Rule Description¶

When adding a detection rule, input the detection conclusion and remediation suggestions. This content will be sent out as the title and description of the alert notification.

1. Define the rule title;
2. Input rule descriptions.
3. Choose to add global labels for the current rule.

Alert Configuration¶

Select an existing alert strategy within the current workspace for association. After the rule is enabled, alerts will be triggered according to the selected alert strategy.

Permissions¶

Set viewing permissions for security monitoring data to enhance data security.
